Silicon alloy steel with a silicon content of 1.0 to 4.5% and a carbon content of less than 0.08% is called silicon steel. It has the characteristics of high permeability, low coercivity, and large resistivity, so the hysteresis loss and eddy current loss are small. Mainly used as magnetic materials in motors, transformers, electrical appliances and electrical instruments. In order to meet the needs of punching and shearing when manufacturing electrical appliances, a certain degree of plasticity is also required. In order to improve the magnetic induction performance and reduce the hysteresis loss, it is required that the content of harmful impurities is as low as possible, and the plate shape is required to be flat and the surface quality is good. etc.
|
Item |
Silicon steel coil |
|
Standard |
ASTM, DIN, ISO, EN, JIS, GB, etc. |
|
Material
|
B50A800、B50A470、B50A1300、Q195、Q235、Q235A、Q235B、Q345、Q345B、Q345C、Q345D、Q345E、Q370 、Q420、 SS400、A36、St52-3、St50-2、S355JR、S355J2、S355NL、A572 Grade 60、A633 Grade A 、SM490A 、HC340LA、 B340LA 、15CRMO 、A709GR50、etc. |
|
Size
|
Thickness: 0.27mm-0.5mm Width: 10mm-1250mm Length: coil as required |
|
Surface |
Semi-organic coating, inorganic coating,Surface coating, black and phosphating, painting, PE coating, galvanizing or as required. |
|
Application
|
Widely used in large motors, medium-sized motors, compressor motors, general purpose vehicles, small precision motors, motors for electric vehicles, anti-theft devices, high-frequency working motors, micro power transformers, instrument transformers, reactors, transformers for welding machines, switches; Power switch, voltage regulator, magnetic sealing unit, accelerator electromagnet, etc. |
|
Export to
|
America, Australia, Brazil, Canada, Peru, Iran, Italy, India, United Kingdom, Arab, etc. |
|
Package |
Standard export package, or as required. |
|
Price term |
EXW, FOB, CIF, CFR, CNF, etc. |
|
Payment |
T/T, L/C, Western Union, etc. |
|
Certificates |
ISO, SGS, BV. |
